Green 750ml Bottle Manufacturing Equipment For Wine

Product Details

Place of Origin: China

Brand Name: JEFFER

Certification: ISO9001, ISO14001, ISO41005

Model Number: Customized

Payment & Shipping Terms

Minimum Order Quantity: 1 set

Price: Negotiable

Packaging Details: Wooden case, Tray, Steel fram.......

Delivery Time: 160 days after received the down payment

Payment Terms: T/T, L/C

Supply Ability: 1 set per 4 months

Get Best Price
Contact Now
Specifications
High Light:

750ml Bottle Manufacturing Equipment

,

750ml glass bottle manufacturing plant

,

ISO41005 Bottle Manufacturing Equipment

Material:
Glass
Application:
Domestic Glass
Capacity:
750ml
Industrial Use:
Drinking
Color:
Amber
Condition:
New
Weight:
200g~250g
Warranty:
1 Year
Voltage:
380V
After-sales Service:
Engineer Overseas Service Available
Material:
Glass
Application:
Domestic Glass
Capacity:
750ml
Industrial Use:
Drinking
Color:
Amber
Condition:
New
Weight:
200g~250g
Warranty:
1 Year
Voltage:
380V
After-sales Service:
Engineer Overseas Service Available
Description
Green 750ml Bottle Manufacturing Equipment For Wine

300ml, Amber Bottle Making, Glass Bottle Production Line, For Beer Bottle





1. Brief introduction



Glass is a special amorphous inorganic nonmetallic material. The main component is silicate, a non-crystalline solid with an irregular structure.



With a good chemical stability and excellent artistry, the glass container has become one of the most popular packing materials. It is also extensively applied in food and beverage industries, which has occupied an important position in the market that cannot be ignored.



Glass melting is the most important process in glass production, it is a forming process where the batched materials form a qualified liquid evenly with no bubbles under high temperature heating.



The melting process is divided into five stages as following, each section has its inner connection, affecting each other. If one stage has imperfect performance, it will influence the next stage, and ultimately affect the quality of glass.



The defect of glass production is mainly due to the melting process, the melting quality has a close relationship with the quality of yield production, production cost, fuel combustion, furnace campaign, etc. It is important to ensure the physicochemical reaction of batched materials perform well during the whole melting process, and make sure the whole process is smoothly operated and for manufacturing high quality glass products.





2. Types of container glass classification



  • Sort by body shape:
Item Description
1 Container / Bottle
2 Container with handle
3 Tubular container
4 Volume: 1ml~25000ml



  • Sort by bottom shape:
Item Description
1 Roundness (majority)
2 Oval
3 Square
4 Rectangle
5 Flat



  • Sort by diameter of bottle neck:
Item Description
1 Wide-mounth bottle or jar
2 The inner diameter of the bottle is over 30mm, with small or no shoulder, which is usually used for semifluid and powder or bulk solid goods.
3
4



  • Sort by bottle mouth and caps:

The diameter and tolerance of bottle mouth is a standard one. The bottle mouth can be divided into screw, cork, pouring, crown cap, roll-on cap, plastic cap, spray mouth, press type mouth, prize up mouth, glass stopper frosted mouth, mouth with handle and tubular type mouth, etc.



  • Sort by requirement of use:
Item Description
Single use bottle Used once and discard it.
Recycle bottle These products  can be recycled and reused many times



  • Sort by forming type:
Item Description
Form by mould The glass liquid will be form a certain type of bottles via mould
Form by tubular method The glass liquid will be stretched into a glass tube and re-manufactured to a required bottle.



  • Sort by color:
Item Description
Flint / Clear Most of the glass containers are flint, which will keep stores more visually.
Green Usually, the green bottle is used for drinks and beers.
Brown / Amber Normally, the brown bottle is for pharmaceuticals or beers, this kind of color can absorb ultraviolet rays, which will help to protect the stores.
Opal This kind of bottle is for cosmetics, vanishing cream, unguent and liquor.





3. Physicochemical changes in each glass melting stage:

  • Silicate forming
In this stage, the components of batched materials will produce a physicochemical solid phase reaction during heating process, in which the gaseous products will be released from the batched materials and produce a new opacity sinter ultimately, which is formed by silicate and SiO2.



  • Glass liquid forming
In this stage, the sinter will be melting and the silicate and SiO2 in sinter will change to flint glass liquid with a plenty of bubbles. However, its chemical components and character are not even.

  • Clearing
The glass liquid is continuously heated, and its viscosity is reduced with plenty of gaseous sundries released, which should eliminate the visible bubbles with the pool of liquid.

  • Homogenization
The glass liquid is kept at high temperature for a long time, the ripple eliminates by diffused function and homogenizes as a whole. The temperature of homogenization can be lower than the clearing stage.

It is the part which melts batched materials and clearing and homogenizes glass liquid. In the upper space of the melting section is referred to as the flame space, the lower part is melting tank. The flame comes from the burner through the port, which feds in preheated air to increase the flame effiency.




4. Main equipment of glass forming



  • Gob Feeder / Serve Gob Feeder
  • I.S. machine
  • Press machine
  • Blowing machine
  • Stacker
  • Transfer ware
  • Conveyor
  • Annealing lehr
  • Packing devices
