Home ProductsGlass Bottle Production Line

Cosmetic Storage Bottle Glass Bottle Production Line Clear Color

Cosmetic Storage Bottle Glass Bottle Production Line Clear Color

  • Cosmetic Storage Bottle Glass Bottle Production Line Clear Color
Cosmetic Storage Bottle Glass Bottle Production Line Clear Color
Product Details:
Place of Origin: China
Brand Name: JEFFER
Certification: ISO9001, ISO14001, ISO41005
Model Number: Customized
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Wooden case, Tray, Steel fram.......
Delivery Time: 180 days after received the down payment
Payment Terms: T/T, L/C
Supply Ability: 1 set per 6 months
Contact Now
Detailed Product Description
Material: Silica Sand, Dolomite, Limestone. Soda Ash.... Application: Glass Industry
Capacity: Customized Industrial Use: Chemical
Color: Flint Condition: New
Weight: 25g~300g Warranty: 1 Year
Voltage: 380V After-sales Service: Engineer Overseas Service Available
High Light:

25g 200ml glass container production

,

25g 200ml glass bottle makers

,

25g glass container production line

Cosmetic Storage Bottle Glass Bottle Production Line Clear Color





1. Brief introduction



Cosmetic Storage Bottle Glass Bottle Production Line is mainly made of soda-lime glass, and the color of the glass is usually clear (flint), amber and green. If the customer requires the one furnace to produce multiple colors of products such as pink, blue, yellow, etc., it can be achieved through special forehearth coloring technology. With its good chemical stability and excellent sensory vision, glass container product is the most widely used packaging containers in the food, beverage and other industry.





2. Typical Techncial Process



The techncial process of glass bottle making is descripbed as the following,



Cosmetic Storage Bottle Glass Bottle Production Line Clear Color 0





3. Heating Energy



We can supply different kinds of heating type furnace. Including:

  • Natural gas
  • Heavy oil
  • Electricity
  • LPG
  • Coal gas
  • Light diesel oil for stand-by

4. Physicochemical changes in each glass melting stage:

  • Silicate forming
In this stage, the components of batched materials will produce a physicochemical solid phase reaction during heating process, in which the gaseous products will be released from the batched materials and produce a new opacity sinter ultimately, which is formed by silicate and SiO2.



  • Glass liquid forming
In this stage, the sinter will be melting and the silicate and SiO2 in sinter will change to flint glass liquid with a plenty of bubbles. However, its chemical components and character are not even.

  • Clearing
The glass liquid is continuously heated, and its viscosity is reduced with plenty of gaseous sundries released, which should eliminate the visible bubbles with the pool of liquid.

  • Homogenization
It is the part which melts batched materials and clearing and homogenizes glass liquid. In the upper space of the melting section is referred to as the flame space, the lower part is melting tank.



5. Techncial Features

  • Three-dimensional (3D) modeling design
  • Single/double/multi pass regenerator
  • Chimney located at the top of regenerator
  • Unique port structure
  • Deep refining technology
  • Unique throat cooling technology
  • Optimized cooling arrangement of melting tank wall
  • Underport burner firing technology
  • Separated-type of regenerator chamber technology
  • Electrical boosting technology
  • Bubbling technology
  • Intelligent single/dual fuel combustion system
  • Rich oxygen combustion technology
  • Full oxygen combustion technology
  • Induced draft fan exhausting technology
  • Injector fan exhausting technology
  • Low energy consumption and long furnace campaign
  • Pre-assembly of key structure
  • Advanced and reliable computer automatic control system (PLC/DCS, SCADA)
  • Low environmental impact
  • Flue gas treatment technology
  • Waste Heat recovery technology



6. FAQ



Q: What does JEFFER do?
A: JEFFER Engineering and Technology Co., Ltd is a professional engineering company specialising in project design, engineering technology consulting, engineering, procurement, construction (EPC), and project operation management.



Q: Can you custom the product?
A: Yes, we design the production line based on the requirement of the client.



Q: How do you control the quaility?
A: All our processes are strictly combined with ISO standard. And our professional team will supervise the quality control during the design and manufacture.



Q: Can you offer design service?
A: Yes, we could design full solution plan as per the requirements of the client.



Q: Do you offer installation on site overseas?
A: Yes, we can provide our engineer to supervise the installation work on site or provide the the whole installation team on site to finish the project.
