Autoclaved Aerated Concrete Production Line

Intelligent Turnkey AAC Block Production Plant with Customizable Product Dimensions

Brand Name:	JEFFER
Model Number:	Customized
MOQ:	1 Set
Price:	USD1million
Delivery Time:	30 Days After Received The Down Payment
Payment Terms:	L/C,T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO9001,ISO14001,ISO45001

Bulk Density:

1/3 Of Ordinary Brickwork Materials

Compressive Strength:

Qualified For Load-bearing And Non-load-bearing Walls

Thermal Conductivity:

Low

Block Length:

600 Mm

Block Width:

200-300 Mm

Block Thickness:

75-250 Mm

Packaging Details:

Wooden Case, Tray, Steel Frame, Etc

Supply Ability:

1 Set Per 1 Months

Highlight:

Intelligent AAC Block Production Plant

Turnkey Autoclaved Aerated Concrete Production Line

Customizable Product Dimensions AAC Manufacturing Line

Product Description

Turnkey AAC Block Production Plant, Intelligent Autoclaved Aerated Concrete Block Manufacturing Line

Core Advantages of Autoclaved Aerated Concrete Building Blocks

Autoclaved Aerated Concrete (AAC) block represents a new generation of lightweight cellular green construction material, offering comprehensive performance superior to traditional clay bricks. With a bulk density only one-third that of ordinary brickwork materials, it significantly reduces building structural load while cutting logistics and transportation costs. The product achieves qualified compressive strength, making it suitable for both load-bearing walls and non-load-bearing infill walls in various construction projects.

Thanks to its closed-cell internal pore structure, AAC blocks feature low thermal conductivity and outstanding thermal insulation performance, greatly improving building energy efficiency. They maintain stable performance under diverse climatic environments with a long service lifespan. On-site processing is convenient: workers can saw, plane, nail, and fix anchors onto blocks using common hand tools, which accelerates construction progress and shortens overall project timelines.

With these advantages, AAC blocks are widely adopted in frame-structure buildings, high-rise residential buildings, seismic-resistant construction zones, and public & commercial buildings with strict energy-saving standards. They also serve as perfect filling and enclosure materials for prefabricated building systems.

Raw Material Matching & Local Material Utilization Benefits

Raw materials required for AAC block manufacturing are easy to source at low cost. Customers can procure most materials locally to reduce logistics expenses and mitigate supply chain risks. Main production raw materials include:

Silica-based materials: fly ash, bottom ash, boiler slag, other industrial waste residues or natural quartz sand
Lime: quicklime, providing heat source for foaming chemical reaction
Cement: ordinary Portland cement, to enhance early-stage strength of green body
Gypsum: minor additive for adjusting setting performance and final finished-product properties
Aluminium agent: aluminium powder or aluminium paste, used as foaming agent to create evenly distributed bubbles inside slurry

We optimize production formulas according to local raw material conditions in the client's region, ensuring favorable production costs and stable long-term material supply after plant commissioning.

Modular Capacity Layout & Customizable Product Dimension Parameters

JEFFER delivers tailor-made complete AAC block production plants with multi-grade capacity options to satisfy different investment budgets and local market demands.

Capacity Grade	Annual Output (m³)	Target Application Scenarios
Small-scale Production Plant	20,000 - 50,000	Regional small & medium block manufacturers, pilot projects for emerging markets
Medium-scale Production Plant	50,000 - 100,000	Regional centralized building-material supply base
Large-scale Production Plant	100,000 - 400,000	Large industrial groups, export-oriented AAC block manufacturing base

Conventional finished AAC block specifications:

Length: 600 mm (standard basic module)
Width: 200-300 mm (adjustable)
Thickness: 75-250 mm (adjustable)
Density grade: 500 kg/m³, 600 kg/m³, 700 kg/m³, customizable to match local energy-saving building codes

Both block dimensions and density grades can be modified according to client order requirements and local construction codes, ensuring full compliance with regional regulatory standards.

Frequently Asked Questions

What core strengths does AAC block have compared with conventional clay bricks?

AAC lightweight blocks offer multiple competitive advantages. First, low density equals one-third the weight of clay bricks, decreasing foundation design load and transport costs. Second, superior heat insulation provides better building energy conservation. Third, autoclave curing supports large-scale continuous mass production. Fourth, industrial solid waste such as fly ash and slag can be recycled as raw materials, conforming to circular economy and environmental protection requirements. Fifth, flexible on-site cutting simplifies construction work and increases masonry working efficiency.

Does JEFFER offer complete equipment supply plus on-site installation service?

Yes, we provide full-scope turnkey solution services. Our scope covers project feasibility analysis, raw-material proportion design, whole-plant layout planning, equipment manufacturing & delivery, on-site installation guidance, commissioning trial runs, and operator skill training. Clients don't need to coordinate with multiple separate vendors. We take charge of full-line system integration and guarantee overall production-line performance indicators.

What public utility conditions are necessary for operating this AAC production plant?

Fundamental utility conditions include four parts: 1. Electric power for driving crushers, grinding mills, mixing units, cutting machines and autoclave systems. 2. Steam supply for autoclave curing process; steam can be generated via coal-fired, gas-fired or biomass boilers. 3. Water resource for slurry mixing and process water supplementation. 4. Compressed air for automatic control and partial process actuation. Exact consumption data will be provided in the feasibility report according to your selected production capacity.

What after-sales support can clients obtain after project hand-over?

Comprehensive long-term after-sales service is guaranteed. After project acceptance and hand-over, we provide remote fault diagnosis, periodic site inspections, production-process optimization suggestions, and genuine original spare-parts supply. Our goal is to ensure stable, high-efficiency operation of your AAC block plant throughout its entire service cycle.
