Dolomite 6mm Construction Glass Plate 500tpd Float Glass Production Line Design

Dolomite 6mm Construction Glass Plate 500tpd Float Glass Production Line Design

Dolomite 6mm Construction Glass Plate 500tpd Float Glass Production Line Design
video
Dolomite 6mm Construction Glass Plate 500tpd Float Glass Production Line Design
Product Details:
Place of Origin: China
Brand Name: JEFFER
Certification: ISO9001, ISO14001, ISO45001
Model Number: Customization
Payment & Shipping Terms:
Minimum Order Quantity: Customization
Price: Negotiable
Packaging Details: Suitable packing for multi-transportation
Delivery Time: 180 days after receiving the down payment
Payment Terms: T/T, L/C
Supply Ability: 2 sets per annually
Contact Now
Detailed Product Description
Name Of Product: Float Glass Capacity: 500tpd
Thickness: 4-12mm Color: Flint
Raw Material: Silica Sand, Dolomite, Limestone...... Application: Construction
Voltage: 380V Condition: New
Waranty: 1 Year Service: Engineers Available To Service Overseas
High Light:

Dolomite Float Glass Line

,

6mm Float Glass Production Line

,

500tpd Construction Float Glass Line

4mm 6mm 8mm 10mm Float Glass Production Line Whole Compelelty Solution


1. Brief Description

The name of float glass is because of the glass liquid floating and forming on a metallic tin liquid surface. By using this forming method, it is not need to overcome the gravity of the glass, it can enlarge the width of the glass, improve the speed of stretch, and increase the capacity and scale of production.

Glass melting is the most important process in glass production, it is a forming process where the batched materials form a qualified liquid evenly with no bubbles under high temperature heating.

JEFFER Engineering and Technology Co., Ltd has already designed and completed equipment supply over different hundreds glass plants in China and abroad.


2. Techncial Advantages


ItemDescription
13D modeling design
2Single/double/multi pass regenerator
3Chimney located at the top of regenerator
4Unique port structure
5Deep refining technology
6Unique throat cooling structure
7Optimized tank wall cooling arrangement
8Underport burner firing technology
9Separate regenerator chamber technology
10Electrical boosting technology
11Bubbling technology
12Intelligent single/dual fuel combustion system
13Rich oxygen combustion technology
14Full oxygen combustion technology
15Induced draft fan exhaust technology
16Injector fan exhaust technology
17Key structure pre-assembly before delivery
18Low energy consumption and long life technology
19Advanced and reliable computer automatic control system (PLC/DCS, SCADA)
20Low environmental impact
21Flue gas treatment technology
22Waste Heat recovery technology



3. Scope of Supply


ItemDescription
1Melting furnace
2Tin batch
3Annealing lehr
4Cold-end equipment
5Cullet return system
6Shielding gas mixing station



4. Raw Materials

Main materials are mainly including:


Silica Sand
Dolomite
Limestone
Feldspar
Soda Ash
Salt Cake
Cullet



Auxiliary materials as the important raw materials, it mainly includes:


Clarify Agent
Coloring Agent
Decolorizing Agent
Oxidizing Agent
Reducing Agent
Combustion Agent



5.  Technical Flow Chart of Float Glass Line


Dolomite 6mm Construction Glass Plate 500tpd Float Glass Production Line Design 0


6. Main Equipment Description


6.1 Batch Plant

For batching and mixing the raw materials.


6.2 Furance

The melting tank is key part of glass production line, the refractory materials quality is very important.


6.3​ Tin Bath
Glass liquid float on the metallic tin, through stretching, forming, polishing and cooling processing, a qualified glass plate is formed and its temperature reduces around 600°C, the transition roller will send the plate to annealing lehr.


6.4.Protection Gas Station

The protection gas station shall operate continuously to produce and supply the required gas for tin bath.

Tin is easy to reaction with oxygen, sulfur under high temperature and form an oxide, its oxide (SnO2, SnO) will seriously pollute the glass liquid, this will affect the quality of the glass.

In the upper space of tin bath, it must be full filled with a protection gas.
Normally, Nitrogen gas (N2) and Hydrogen gas (H2) gas are to be used as protection gas. Which is mainly for preventing or reducing the oxidation of metallic tin liquid.

6.5. Annealing Lehr
In glass technology, annealing means to put the glass into the annealing lehr for a certain time or reduce the temperature with a slow speed, so as to no additional permanent stress or temporary stress will produce. Namely, annealing also means a process which will reduce or eliminate the thermal stress of glass.


6.6. Colde-end


It mainly divides into three sections for cold-end part in float glass production line. Details are following:
  • Inspection and pretreatment section
  • Cutting and break section
  • Stacker and packing section


Dolomite 6mm Construction Glass Plate 500tpd Float Glass Production Line Design 1


7. FAQ

Q: Who we are?
A: JEFFER Engineering and Technology Co., Ltd is a professional engineering company specialising in project design, engineering technology consulting, engineering, procurement, construction (EPC), and project operation management.

Q:Can you offer design service?
A: Yes, we could design full solution drawings as per your requirements.

Q: How can I get the price
A: For product line, please provide the detailed specfication of the production you want to product, then we will privode an economic plan for your reference. For engineering service, please provide your requirement, we will provide the detailed schedule and plan for your reference.

Q: Which shipment is available?
A: By sea, by air, by rail or as your requirement.
