Customization 10mm Float Glass Production Line Flint Limestone

Product Details

Place of Origin: China

Brand Name: JEFFER

Certification: ISO9001, ISO14001, ISO45001

Model Number: Customization

Payment & Shipping Terms

Minimum Order Quantity: Customization

Price: Negotiable

Packaging Details: Suitable packing for multi-transportation

Delivery Time: 180 days after receiving the down payment

Payment Terms: T/T, L/C

Supply Ability: 2 sets per annually

Get Best Price
Contact Now
Specifications
High Light:

Limestone Float Glass Line

,

Flint Float Glass Production Line

,

10mm Float Glass Line

Name Of Product:
Float Glass
Capacity:
300tpd
Thickness:
4-12mm
Color:
Flint
Raw Material:
Silica Sand, Dolomite, Limestone, Soda Ash
Application:
Construction
Voltage:
380V
Condition:
New
Waranty:
One Year
Service:
Engineers Available To Service Overseas
Name Of Product:
Float Glass
Capacity:
300tpd
Thickness:
4-12mm
Color:
Flint
Raw Material:
Silica Sand, Dolomite, Limestone, Soda Ash
Application:
Construction
Voltage:
380V
Condition:
New
Waranty:
One Year
Service:
Engineers Available To Service Overseas
Description
Customization 10mm Float Glass Production Line Flint Limestone

4mm 6mm 8mm 10mm Float Glass Production Line Whole Compelelty Solution


1. Brief Description

The name of float glass is because of the glass liquid floating and forming on a metallic tin liquid surface. By using this forming method, it is not need to overcome the gravity of the glass, it can enlarge the width of the glass, improve the speed of stretch, and increase the capacity and scale of production.

JEFFER Engineering and Technology Co., Ltd has already designed and completed equipment supply over different hundreds glass plants in China and abroad.


2. Techncial Advantages


Item Description
1 3D modeling design
2 Single/double/multi pass regenerator
3 Chimney located at the top of regenerator
4 Unique port structure
5 Deep refining technology
6 Unique throat cooling structure
7 Optimized tank wall cooling arrangement
8 Underport burner firing technology
9 Separate regenerator chamber technology
10 Electrical boosting technology
11 Bubbling technology
12 Intelligent single/dual fuel combustion system
13 Rich oxygen combustion technology
14 Full oxygen combustion technology
15 Induced draft fan exhaust technology
16 Injector fan exhaust technology
17 Key structure pre-assembly before delivery
18 Low energy consumption and long life technology
19 Advanced and reliable computer automatic control system (PLC/DCS, SCADA)



3. Scope of Supply


Item Description
1 Melting furnace
2 Tin batch
3 Annealing lehr
4 Cold-end equipment
5 Cullet return system
6 Shielding gas mixing station



4. Raw Materials

Main materials are mainly including:


Silica Sand
Dolomite
Limestone
Feldspar
Soda Ash
Salt Cake
Cullet



Auxiliary materials as the important raw materials, it mainly includes:


Clarify Agent
Coloring Agent
Decolorizing Agent
Oxidizing Agent
Reducing Agent
Combustion Agent



5.  Technical Flow Chart of Float Glass Line


Customization 10mm Float Glass Production Line Flint Limestone 0


6. Main Equipment Description


6.1 Batch Plant

For batching and mixing the raw materials.


6.2 Furance

The melting tank is key part of glass production line, the refractory materials quality is very important.


6.3​ Tin Bath
Glass liquid float on the metallic tin, through stretching, forming, polishing and cooling processing, a qualified glass plate is formed and its temperature reduces around 600°C, the transition roller will send the plate to annealing lehr.


6.4.Protection Gas Station

The protection gas station shall operate continuously to produce and supply the required gas for tin bath.

Tin is easy to reaction with oxygen, sulfur under high temperature and form an oxide, its oxide (SnO2, SnO) will seriously pollute the glass liquid, this will affect the quality of the glass.


6.5. Annealing Lehr
In glass technology, annealing means to put the glass into the annealing lehr for a certain time or reduce the temperature with a slow speed, so as to no additional permanent stress or temporary stress will produce. Namely, annealing also means a process which will reduce or eliminate the thermal stress of glass.


6.6. Colde-end


It mainly divides into three sections for cold-end part in float glass production line. Details are following:
  • Inspection and pretreatment section
  • Cutting and break section
  • Stacker and packing section


Customization 10mm Float Glass Production Line Flint Limestone 1


7. FAQ

Q: Who we are?
A: JEFFER Engineering and Technology Co., Ltd is a professional engineering company specialising in project design, engineering technology consulting, engineering, procurement, construction (EPC), and project operation management.

Q:Can you offer design service?
A: Yes, we could design full solution drawings as per your requirements.

Q: How can I get the price
A: For product line, please provide the detailed specfication of the production you want to product, then we will privode an economic plan for your reference. For engineering service, please provide your requirement, we will provide the detailed schedule and plan for your reference.

Q: Which shipment is available?
A: By sea, by air, by rail or as your requirement.
