White Soup Bowl Opal 5 Inch Glass Making Machinery

White Soup Bowl Opal 5 Inch Glass Making Machinery

  • White Soup Bowl Opal 5 Inch Glass Making Machinery
  • White Soup Bowl Opal 5 Inch Glass Making Machinery
White Soup Bowl Opal 5 Inch Glass Making Machinery
Product Details:
Place of Origin: China
Brand Name: JEFFER
Certification: ISO9001, ISO14001, ISO45001
Model Number: Customized
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Wood case, tray, steel frame........
Delivery Time: 90 days after received the down payment
Payment Terms: T/T, L/C
Supply Ability: 1 set per 3 month
Contact Now
Detailed Product Description
Material: Silica Sand, Fluor Color: White
Size: 5” Application: Domestic Glass
Shape: Customized Votalge: 380V
Condition: New Capacity: Customized
Warranty: 1 Year Service: Engineer Overseas Service Available
High Light:

5Inch Opal Glass Making Machinery


5Inch Glass Making Machinery


5Inch ODM Opal glass making machine

5 Inch, Glass Soup Bowl, Glass Processing Plant, Opal Glass Making Machinery



1. Brief introduction

Glass is a special amorphous inorganic nonmetallic material. The main component is silicate, a non-crystalline solid with an irregular structure.


Opal glass is a kind of glass material formed by opactifying effection produced from tiny particle in fluoride via light scatting effect.


At present, the opal glass is a regularly used glass product in daily life.



2. Advantage


  • Increase the strength and thermal impacting property of the glass product.
  • Increase the decoration apperance of the glass product.


3. Materials of opal glass

Stable chemical components in the raw materials are very important, especially the content of fluor and sodium fluosilicated, which will affect the opacifying effect.


To produce high quality product of opal glass, a high quality of silica sand shall be reqruied. The main materials to produce opal glass are below,


Item Description
1 Silica sand
2 Aluminium hydroxide / Feldspar
3 Fluor / sodium fluosilicated
4 Calcite / limestone


Glass melting is a very complex process, it includes physical, chemical and physicochemical phenomena and reaction. These phenomena and reaction lead the mechanical mixed raw materials to complex melting glass liquid.



4. Main equipment of forming device

  • Gob Feeder / Serve Gob Feeder

Shear angle:adjustable between RH30°- LH 90°
Available for S.G, D.G and T.G.


  • Press machine

Use continue cam in different section.
Pneumatic mold clamping, usually use 5 bar compressor air for stronger clamping the mold.


  • Transfer ware

Transfer ware is designed for conveying the glass product from I.S.machine or press machine to cross conveyor in front of the annealing lehr quickly and stably, which is especially applicable to high-speed glass production line.


  • Cross Conveyor

Cross conveyor is installed in front of annealing lehr for cross conveying the glass product and works with stacker to push them into annealing lehr.


  • Stacker

Stacker is used for pushing the glass product from the cross conveyor into annealing lehr. Pushing speed is adjusted by inverter, quantity of pushing numbers is controlled by digital counters.


  • Annealing lehr

Annealing lehr can be continuous annealing of tableware, bottles, cans, and other glass products.


  • Packing devices

Different kinds of packing devices could meet different packing types of different kinds of domestic glass products.
