30Tpd Thickness 0.8mm Sheet Glass Production Line Manufacturing Machine

Flint Sheet Glass, 30TPD, 0.8mm Thickness, Sheet Glass Making Machine

1. Brief Description


Glass is a special amorphous inorganic nonmetallic material. The main component is silicate, a non-crystalline solid with an irregular structure.

Production process of sheet glass was created by Belgium Glaverbel Company in 1961.  Under this kind of process, it can achieve a glass thickness from 0.8mm to 12mm.

Glass melting is the most important process in glass production, it is a forming process where the batched materials form a qualified liquid evenly with no bubbles under high temperature heating.

The melting process is divided into five stages as following, each section has its inner connection, affecting each other. If one stage has imperfect performance, it will influence the next stage, and ultimately affect the quality of glass.

2. Characteristic

3. Scope of Supply

• Raw material treatment system
• Internal and external cullet system
• Glass furnace
• Forming device
• Cold end device
• Utlity equipemnt
• Auto control system

4. Main Equipment Description


• Batch Plant

For batching and mixing the raw materials.


• Furnace

The melting tank is key part of glass production line, the refractory materials quality is very important.


• Forming

Compared with the float glass process, the sheet glass is combined with slotless process and horizontal stretching process, forming the glass liquid by slotless tank and stretching rotation method.

• Annealing Lehr

In glass technology, annealing means to put the glass into the annealing lehr for a certain time or reduce the temperature with a slow speed, so as to no additional permanent stress or temporary stress will produce. Namely, annealing also means a process which will reduce or eliminate the thermal stress of glass.


5. Application

This type of ultrathin glass is mainly used for instrument, electrics and crafts manufacturing.
