50 Ton Per Day Glass Melting Furnace Design And Construction

50 Ton Per Day Glass Melting Furnace Design And Construction

  • 50 Ton Per Day Glass Melting Furnace Design And Construction
50 Ton Per Day Glass Melting Furnace Design And Construction
Product Details:
Place of Origin: China
Brand Name: JEFFER
Certification: ISO9001, ISO14001, ISO45001
Model Number: Customized
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Wooden case, tray, steel frame, etc
Delivery Time: 180 days after received the down payemnt
Payment Terms: T/T, L/C
Supply Ability: 1 set per 6 months
Contact Now
Detailed Product Description
Capacity: 50tpd Material: Refractory Materials And Steel Structure
Kind Of Glass: Soda-lime Type: Automatic Control
Condition: New Kind Of Fuel: Natural Gas
Consumption: Energy Saving Waranty: 12 Months
Application: Glass Industrial After-salses Service: Engineering Available
High Light:

50 T/D Glass Melting Furnace Design

,

50tpd Glass Melting Furnace Design

,

50tpd electric glass melting furnace

50 Ton Per Day Glass Melting Furnace Design And Construction​​





1. Brief Description of Glass for 50 Ton Per Day Glass Melting Furnace Design And Construction
  • Glass melting is the most important process in glass production, it is a forming process where the batched materials form a qualified liquid evenly with no bubbles under high temperature heating.
  • Glass melting is a very complex process, it includes physical, chemical and physicochemical phenomena and reaction. These phenomena and reaction lead the mechanical mixed raw materials to complex melting glass liquid.

JEFFER Engineering has designed and supplied a variety of glass melting furnaces for the customers in China and aboard, ranging from the end fired furnace to the electric furnace; from very small scale pot furnace to large float glass furnace of 50 Ton Per Day Glass Melting Furnace Design And Construction



50 Ton Per Day Glass Melting Furnace Design And Construction 0





2. Type of Glass Melting Furnace for 50 Ton Per Day Glass Melting Furnace Design And Construction:
  • End fired regenerative furnace
  • Cross fired regenerative furnace
  • Recuperative furnace
  • Full-Oxygen furnace
  • Electric furnace
  • Pot furnace



3. Heating Energy of 50 Ton Per Day Glass Melting Furnace Design And Construction



We can supply different kinds of heating type furnace. Including:

  • Natural gas
  • Heavy oil
  • Electricity
  • LPG
  • Coal gas
  • Light diesel oil for stand-by



4.Supply of Equipment & Material  for 50 Ton Per Day Glass Melting Furnace Design And Construction
  • Refractory materials
  • Combustion equipment
  • Mechanical equipment
  • Electric equipment, Instrument, and automatic control equipment
5. Structure of Furnace for 50 Ton Per Day Glass Melting Furnace Design And Construction
  • Glass melting section
  • Heat source supply section
  • Waste heat recovery section
  • Gas supply and waste gas exhaust

Cooling section of 50 Ton Per Day Glass Melting Furnace Design And Construction:

It is a part for cooling and homogenization of the glass liquid, which is also an access for glass liquid distribution.



Air, gas access of 50 Ton Per Day Glass Melting Furnace Design And Construction:

The heated air and gas flow into the pre-combustion room for mixing via this access after they flow out of the regenerator. This is also an access for the flue gas to flow into the regenerator from the flame space.



Reasonable melting technology is a system which could ensure a normal daily production. It will have an important function for high production, high quality, low consumption and furnace campaign.



6. FAQ

Q: Who we are?



A: JEFFER Engineering and Technology Co., Ltd is a professional engineering company specialising in project design, engineering technology consulting, engineering, procurement, construction (EPC), and project operation management.





Q:Can you offer design service of 50 Ton Per Day Glass Melting Furnace Design And Construction?



A: Yes, we could design full solution drawings as per your requirements.





Q: How can I get the price of 50 Ton Per Day Glass Melting Furnace Design And Construction?



A: For product line, please provide the detailed specfication of the production you want to product, then we will privode an economic plan for your reference. For engineering service, please provide your requirement, we will provide the detailed schedule and plan for your reference.

50 Ton Per Day Glass Melting Furnace Design And Construction 1
