Big Capacity ISO45001 50Hz Glass Furnace Melting Device

Name: Big Capacity ISO45001 50Hz Glass Furnace Melting Device
Brand: JEFFER Engineering and Technology Co.,Ltd
SKU: Customized
Availability: InStock

Brand Name:	JEFFER
Model Number:	Customized
MOQ:	1 set
Price:	Negotiable
Delivery Time:	180 days after received the down payment
Payment Terms:	T/T, L/C

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO9001, ISO14001, ISO45001

Condition:

New

Voltage:

380V, 50Hz

Dimension:

Customized

Application:

Glass Industry

Products:

Domestic Glass

Waranty:

One Year

Type:

Cross Fired Furnace

Fuel Type:

Heavy Oil

Color:

Customized

After-sales:

Engineers Available To Service Machinery Overseas

Packaging Details:

Wooden case, steel frame

Supply Ability:

1 set per 6 month

Highlight:

50Hz Glass Furnace Melting Device

ISO45001 glass melting furnace

ISO45001 Glass Furnace Melting Device

Product Description

Big Capacity of Glass Furnace Melting Device, Cross Fired Furnace

1. Brief Introduction

Glass furnace is a melting device, which is the most necessary and important equipment for the glass industry.

The melting process is divided into five stages as following, each section has its inner connection, affecting each other. If one stage has imperfect performance, it will influence the next stage, and ultimately affect the quality of glass.

The direction of flames of a cross fired furnace is from one side to the other side, which is across the width of the furnace and perpendicular with the flow direction of glass liquid.

Glass melting is a very complex process, it includes physical, chemical and physicochemical phenomena and reaction. These phenomena and reaction lead the mechanical mixed raw materials to complex melting glass liquid.

Big Capacity ISO45001 50Hz Glass Furnace Melting Device 0

2. Feature

1	High productivity
2	Longitudinal temperature adjustable

3. Structure of furance

1	Melting section
2	Breast wall
3	Crown
4	Port
5	Regenerator
6	Cooling section
7	Flue channel
8	Double deck reversing unit
9	Waste heat treatment system

4. Main component

Melting tank

The melting tank is combined with melting area and clearing area.

Regenerator

The regenerator as a waste heat recovery device, the combustion air flows through the regenerator, after preheated, it will arrive at the furnace through the port.

Port

It is the place where the fuel is mixed with the preheated air, also an access for the preheated air in to the furnace and exhausting the

waste gas out.
